NIIMBOT B4
4-inch portable smart label printer for high-visibility merchant mobile-money QR payments, with RFID support and an 80 mm/s engine.
Gallery
Wide-format merchant QR labels for counters and collection points
Axon-styled overview of the B4 technical specification
Overview
The NIIMBOT B4 is the wide-format member of the range for merchant mobile-money solutions — producing large, highly visible QR payment labels for counters, kiosks and collection points. This 4-inch battery-powered thermal printer prints up to 104 mm wide at 203 dpi and 80 mm/s over Bluetooth or USB. Automatic paper positioning and smart media recognition handle gap, black-mark and transparent stock, while the 16,000-template library also supports logistics, retail and asset-management labels.
Who It's For
- Bulk SIM distribution and shipping labels
- Warehouse and logistics labelling for device fleets
- RFID-enabled asset tagging of enrolment hardware
- Wide-format compliance and evidence labels
- Mobile-money merchant QR labels for counter and collection-point operations
- Batch serialised label runs for registration campaigns
Key Capabilities
104 mm Print Width
4-inch format at 203 dpi — shipping labels, multi-field asset plates, compliance notices and A6-scale documents that will not fit a 48 mm roll.
80 mm/s Print Engine
Prints up to 80 mm/s with a print head rated for 50 km of service life, for sustained batch runs rather than occasional labels.
Battery-Powered Portability
2,000 mAh battery in a 757 g, 157 × 135 × 69 mm body — untethered operation across a warehouse floor or a field deployment.
RFID & Smart Recognition
RFID support with automatic paper positioning and smart media recognition across gap, black-mark and transparent stock.
16,000+ Templates
A template library spanning logistics, retail, warehousing and asset management, with batch printing for serialised runs.
Merchant QR-Payment Labels
Generate and print large, scannable mobile-money QR labels through the connected merchant workflow — designed for counter display, kiosks and collection points.
Bluetooth & USB
Connects over Bluetooth to Android and iOS handhelds, or by USB to a PC workstation.
Technical Specifications
Technical Data
| Print method | Direct thermal |
| Print resolution | 203 dpi |
| Print speed | Up to 80 mm/s |
| Print width | 104 mm effective |
| Print height | 8–350 mm |
| Print head life | 50 km |
| Label width | 20–108 mm |
| Black-mark / transparent | 20–300 mm height |
| Positioning | Automatic paper positioning |
| Recognition | Smart media recognition |
| RFID | Supported |
| Wireless | Bluetooth |
| Wired | USB |
| Host devices | Android · iOS · PC |
| Battery capacity | 2,000 mAh |
| Dimensions | 157 × 135 × 69 mm |
| Weight | 757 g |
| Templates | 16,000+ built-in |
| Batch printing | Supported |
